Solution to Micro:bit Power Problem

标签:DIY

LUCY 发布于 2018-01-19 16:36


Today I am going to talk with you something about micro:bit power supply. All of you who had played micro:bit know that it has three power methods:


  1. Power through USB connector;
  2. Power through JST battery terminal connector;
  3. Power through its bottom edge connector.


Let's look at a chart from micro:bit official:



We can know from this chart that if we power by USB, it can provide 120mA current at most. Except for 30mA consumpted by the board itself, it can also provide 90mA current to the external module or sensor through the edge connector. With 90mA only, it can even hardly to drive a servo properly. Thus USB is not a good power choice.

But what if we power by  battery connector? The voltage of single AA or AAA battery is 1.5V. Two batteries in parallel connection is just 3V. As with the usage of the battery, the power will be lesser and lesser, and the voltage will be lower and lower. Suppose if we use micro:bit to drive analog voltage sensor(such as  analog temperature sensor), the test accuracy will become lower as with the consumption of the battery power. Besides, it is not environment-protect to use battery frequently. Even if we use the re-chargeable Ni-MH battery, it is not good too. Because the voltage of a single rechargeable battery is only 1.2V, and two in parallel is 2.4V, so some sensors may not work normally due to the low voltage. Therefore, battery is not a stable power source too.

Then here comes the question: Is there a power method that supplies both abundant power and stable voltage? Of course, there is. Today, I am going to show you a product: Micro:bit Power Supply Module


This battery supports two input methods: one is to input by micro USB terminal, the other is to input by DC terminal. The most convinient point is its output port can be directly connected to  battery connector just like the picture showed below:



After several days trial, I have made a conclusion for its advantages. Here is my conclusion:

  1. Enable to power by USB connector. When we use USB connector to charge, what we need to pay attention is if we want to obtain a bigger current(like drive servo or motor), we'd better not to power by USB but to use portable power supply. Because some boards have current protection function, while the USB connectot can only output 500mA.
  2. Can power through DC power, available for 5V to 12V. If you have DC power supply of Arduino, you don't have to buy other DC power supply.
  3. The output voltage is stable around 3.2V, which can make sure the accuracy of the sensor.
  4. The output can connect micro:bit  battery connector directly. It has good compatibility.

Want to know how much powerful the micro:bit power supply module is? You can watch the video below.


In the video, micro:bit power supply module powered by DC terminal has driven:
three channels of servos,

ESP8266wifi module,

PM2.5 module,

dust sensor,

noise sensors,

buzzer,

OLED screen,

which arrives 10 components in total, at the same time.
